Why Nut Shell Activated Carbon is Revolutionizing Industrial Water Purification Systems?

1. Introduction

In modern **industrial water treatment systems**, **shell-based activated carbon** (from coconut, walnut, or peach

shells) has become the **preferred choice** for removing organic pollutants, heavy metals, and discoloration. With

its **high adsorption capacity** and **eco-friendly properties**, it outperforms traditional coal-based carbon in many

applications.

This guide covers:

✔ **Why shell carbon works better for water treatment**

✔ **Key applications in industrial purification**

✔ **How to select the optimal carbon for your system**

---

2. Advantages of Shell Activated Carbon in Water Treatment

✅ Superior Adsorption Performance

- **Higher micropore volume** → Better removal of **COD, BOD, and organic pollutants**

- **Iodine value 500-900 mg/g** vs 800-900 mg/g for coal carbon

✅ Excellent Physical Propertie

- **High hardness (≥95%)** → Less breakage in continuous-flow systems

- **Low ash content (<5%)** → Minimizes leaching of impurities

✅ Cost-Effective Operation

- **Longer service life** → 20-30% more regeneration cycles than coal carbon

- **Lower pressure drop** → Reduces energy costs in filtration systems

✅ Environmentally Friendly

- **Made from renewable resources** (coconut/walnut shells)

- **Biodegradable** and non-toxic

---

3. Key Applications in Water Treatment

① Industrial Wastewater Treatment

- Removes **phenols, dyes, and pesticides** from chemical plant effluent

- **Case Study:** A textile factory reduced **COD by 92%** using our shell carbon

② Drinking Water Purification**

- Eliminates **chlorine, THMs, and micropollutants**

- Meets **WHO and EPA standards** for potable water

③ Heavy Metal Removal**

- Effective for **lead, mercury, cadmium, and arsenic** adsorption

- **pH range 4-10** for optimal performance

④ Aquaculture & Fisheries

- Maintains water clarity by removing **ammonia and organic waste**

---

4. Technical Specifications

item		First Grade	Second Grade
Particle Size 6-16 Mesh  10-24Mesh	%	≥95	≥95
iodine Sorption Value	mg/g	≥1000	≥900
Intensity	%	≥95	≥95
Moisture	%	≤10	≤10
Ash	%	≤3	≤3
Filling Specific	g/cm³	0.4-0.45	0.45-0.5
PH		6-9	6-9

---

5. How to Select the Right Shell Carbon?

⚠️ 3 Common Mistakes to Avoid

1. **Choosing wrong particle size** → Too fine = high pressure drop; too coarse = poor adsorption

2. **Ignoring reactivation potential** → Increases long-term costs

3. **Overlooking certifications** → NSF/ANSI 61 for drinking water applications

✅ Selection Guide**

✔ **For wastewater:** 8×30 mesh granular carbon

✔ **For drinking water:** 20×50 mesh with acid washing

✔ **For heavy metals:** Sulfur-impregnated shell carbon

---

6. System Design & Maintenance Tips

- **Contact time:** 15-30 minutes for optimal adsorption

- **Backwash frequency:** Every 2-4 weeks depending on turbidity

- **Reactivation:** Thermal regeneration at 700-900°C restores 85-90% activity

---

7. Why Choose Our Shell Activated Carbon?*
